Operation modes |
active, passive |
|
The number of active channels |
2 |
|
Signal type |
phase-shift keyed |
|
Peak transmitted power, W |
100 |
|
Low- power mode transmitter |
has |
|
Operating range, nm |
up to 64 |
|
Minimum range, m |
≤ 60 |
|
Signal type |
pulse |
|
Peak transmitted power, W |
≥ 5 |
|
Operating range, miles |
up to 24 |
|
Rotation speed of antenna, rpm |
10 |
|
Operation frequency, MHz |
9430± 30 |
|
Frequency range, GHz |
0,1-18 |
|
Receiving sector, degree |
360 |
|
Bearing accuracy from 1 up to 2 GHz, degree |
12 |
|
Bearing accuracy from 2 up to 18 GHz, degree |
10 |
|
Precising frequency measuring |
has |
|
Main display |
20˝ сolor LCD 1600×1200 |
|
Tracking target number |
≥ 50 |
|
Maximum power consumption |
≤ 3,5 kW |
|
Mains |
one-phase AC 220 V 400 Hz or DC 175-320V |
|
Common weight, carrying SPTA |
≤ 900 kg |
